Lithium Primary

Batteries

If your application requires a long-lasting one-time-use battery solution, Tenergy has the cells that you need, along with the technical expertise to ensure that you are getting the best quality products for your money.  As a reliable supplier to several government agencies and private contractors, Tenergy is capable of supporting your business.

3.0V 1400mAh Lithium-Manganese Dioxide CR123A Size Primary Battery Cell
  • Max. continuous discharge current: 1A

  • Dimensions: 34.5mm x 17mm (LxD)

  • Weight: 17g

Item No. 30350

3.6V 1200mAh Lithium-thionyl Choride
1/2 AA Size Primary Battery Cell
  • Max. continuous discharge current: 15mA

  • Max Pulse capability: 50mA

  • Dimensions: 25.4mm x 14.5mm (LxD)

  • Weight: 10g

Item No. 30300-0

3.6V 1650mAh Lithium-thionyl Choride
2/3 AA Size Primary Battery Cell
  • Max. continuous discharge current: 35mA

  • Max Pulse capability: 75mA

  • Dimensions: 33.5mm x 14.5mm (LxD)

  • Weight: 12g

Item No. 30324-0

3.6V 2700mAh Lithium-thionyl Choride
AA Size Primary Battery Cell
  • Max. continuous discharge current: 50mA

  • Max Pulse capability: 150mA

  • Dimensions: 50.5mm x 14.5mm (LxD)

  • Weight: 19g

Item No. 30304-0

3.6V 3600mAh Lithium-thionyl Choride
A Size Primary Battery Cell
  • Max. continuous discharge current: 130mA

  • Max Pulse capability: 180mA

  • Dimensions: 51mm x 17.5mm (LxD)

  • Weight: 26g

Item No. 30323-0

3.6V 4000mAh Lithium-thionyl Choride
A Size Primary Battery Cell
  • Max. continuous discharge current: 130mA

  • Max Pulse capability: 180mA

  • Dimensions: 50.5mm x 18.7mm (LxD)

  • Weight: 28g

Item No. 30322-0

3.6V 8500mAh Lithium-thionyl Choride
C Size Primary Battery Cell
  • Max. continuous discharge current: 150mA

  • Max Pulse capability: 300mA

  • Dimensions: 50mm x 26.2mm (LxD)

  • Weight: 52g

Item No. 30321-0

3.6V 19Ah Lithium-thionyl Choride
D Size Primary Battery Cell
  • Max. continuous discharge current: 23mA

  • Max Pulse capability: 400mA

  • Dimensions: 61.5mm x 33.1mm (LxD)

  • Weight: 100g

item No. 30312-0

3.6V 35Ah Lithium-thionyl Choride
DD Size Primary Battery Cell
  • Max. continuous discharge current: 420mA

  • Max Pulse capability: 500mA

  • Dimensions: 124.5mm x 33.1mm (LxD)

  • Weight: 195g

item No. 30309-0

6V 1400mAh (8.4Wh)
Lithium Primary Battery with Diode, PTC & Connector
  • Max. continuous discharge current: 1.0A

  • Max Pulse capability: 2.5A

  • Dimensions: 20mm x 69.5mm (LxD)

  • Weight: 35g

item No. 34121
